10L Accumulate Blow Moulding Machine

Model:KGB70A

KGB70A is a versatile 10L Accumulate Blow Moulding Machine designed for max 15-liter bottle blow molding. As a leading water bottle machine manufacturer, we offer customized solutions to meet customer's requirements. The machine is not only for water bottles, pesticide containers, and daily chemical packaging production, but also for small but special shape products. This machine meets diverse needs.

Volume : 20LWeight : 7.8T

Send Inquiry

Product Description Specification Application

KGB70A 10L Accumulate Blow Moulding Machine is a fixed opening and closing model, which adopts double pull rod synchronous clamping mechanism, oil cylinder direct pressure locking mold, accumulator cylinder die head serise. Hydralic servo system control, fast response speed and energy saving.
More suite for those special design shape product production, can control the shape and thickness more accuracy.

Features and Advantages

This model is a fixed opening and closing mold, using a double tie rod synchronous film closing mechanism, and the oil cylinder direct pressure locks the mold
● Storage cylinder die head series
● Maximum volume 20L
● Suitable for water bottles, pesticide containers, and daily chemical packaging, etc.
● The distinctive feature is that it is controlled by a hydraulic servo system to achieve fast action response and high energy efficiency.

Specifications

serial number	Material PE、PP、ABS ...	Mold closing oil cylinder(single cylinder)
serial number	Material PE、PP、ABS ...	Machine model:KGB70A
Specifications
1	Max container capacity	20L
2	Output(dry Cycle)	700 PC/HR
3	Machine Dimension(L×W×H)	4.3 M x1.7 M x3.9 M
4	Machine weight	7.8 T
Clamping Unit
1	Clamping force	130 KN
2	Mold platen size(W×H)	680 MM x 600 MM
3	Platen openingstroke	300 MM - 850 MM
4	Platen moving stroke	370 MM
5	Max mold size(W×H)	460 MM×600 MM
6	Mold thickness	310 MM - 380 MM
Power
1	Servooil pump motor power	11KW
2	Servo pump displacement	80 L/MIN
3	Blowpressure	0.8 Mpa
4	Air consumption	0.7 M²/MIN
5	Cooling water pressure	0.3 Mpa
6	Water consumption	60 L/min
7	Average energy consumption	18 KW-22 KW
Extruder unit
1	Screw diameter	70 MM
2	Screw L/D ratio	24 L/D
3	Melting capacit for HDPE	80 Kg/hr
4	Number of heating zone	3 ZONE
5	Screw heating power	12.6 KW
6	Screw fanpower	0.5 KW
7	Extruder motor power	22 KW
Die head
1	Number of heating sections	5 ZONE
2	Heating power	20 KW
3	Maxdie-pin diameter	180 MM
4	Accumulator capacity	3 L
5	(PE)Accumulator weight	2.25 KG
